Every trail, every steep climb, every thrilling descent.
Tested and developed by Giant’s E-bike enduro pros, this proven trail ripper gives you the power to enjoy the best parts of the ride again and again.
Key Features & Benefits:
- Updated Geometry:A shorter rear end and longer reach allow superior handling and agility on technical terrain.
- Trail Technology:Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor technology boost your capabilities on steep climbs and rugged descents.
- Total Control:RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.
Full Specification:
- Frame:ALUXX SL-grade aluminium, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, ‘Boost’ 148x12mm, Universal Derailleur Hanger
- Fork:RockShox ZEB Select 29er, 170mm travel, Charger RC damper, 15×110 Boost, Maxle Stealth, E-bike Approved
- Rear Shock:FOX Float X Performance, EVOL Large Volume sleeve, 2-position lever, 205×62.5mm Trunnion mount, custom tuned
- Motor:Giant SyncDrive Pro2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
- Controller:Giant RideControl Ergo3, grip integrated remote
- Display:Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
- Battery:Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production Giant EnergyPak Plus 250 range extender compatible (exculde S size)
- Charger:Giant EnergyPak 6A smart charger, 60% in 3:00h
- Number of Gears:12
- Gear Shifters:Shimano Deore SLX
- Chainset:Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)
- Chainrings:36T
- Rear Cassette:Shimano HG-M6100, 10-51T, 12-speed
- Chain:KMC e.12 Turbo, EcoProteq, e-bike optimised
- Front Derailleur:MRP HD2 co-moulded chain guide
- Rear Derailleur:Shimano Deore SLX, 12-speed, Shadow+
- Bottom Bracket:Giant Integrated
- Pedals:Flatpedal
- Rims:Giant AM 29″ [F] 27.5″[R], Tubeless ready, 30mm inner width
- Front Hub:Shimano MT410 Boost, Center-Lock
- Rear Hub:148x12mm Micro-Spline Drive Body Thru-axle
- Front Tyre:Maxxis Minion DHF 29×2.6″ foldable, Tubeless, EXO+, 3C MaxxTerra
- Rear Tyre:Maxxis High Roller II 27.5×2.5″ foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound
- Brakes:Shimano SLX BR-M7120, 4-piston, hydraulic disc, 203mm
- Handlebars:Giant Contact Trail, 35x800mm
- Handlebar Grips:Giant Tactal Pro-E, single lock-on
- Stem:Giant Contact SL 35
- Saddle:Giant Romero Trail
- Seatpost:Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
- Accessories:Tubeless kit (liquid, valves, levers, manual, tool), Torx 25 Battery Lock with built-in Torque limiter
- Weight:N/A
